PTM-210G series high frequency dynamic pressure sensor
PTM-210G series high frequency dynamic pressure sensor
PTM-210G series high frequency dynamic pressure sensor
PTM-210G series high frequency dynamic pressure sensor

PTM-210G series

High frequency dynamic pressure sensor
PTM-210G series high frequency dynamic pressure sensor combined with high frequency dynamic sensing element, optional frequency response from 3kHz~260kHz, great circuit design can directly convert the sensor signal into available electrical signal, greatly reduce the frequency response brought by the transmission at any time, with high response speed, durability, high precision characteristics, It is especially suitable for test equipment, experimental equipment, aerospace test requiring fast response speed.
Inquiry this Products
Product Selection
Expert Q&A
5% off for new customers
Specification
Technical parameters
Document
Specification
Performance Features
■ Measuring media: dry gas, gas, liquid, slightly corrosive liquid, viscous liquid

■ Measuring range :-0.1-70MPa

■ Comprehensive accuracy :±0.25%FS

■ Diaphragm material :316L stainless steel

■ Operating temperature :-35-80℃

■ Overload pressure :150%FS

■ Bursting pressure :200%FS

■ Output: 4-20mA, 0-5V, 0-10V, etc

■ Process connection: thread

■ Protective connection: Horseman connector, direct connection, waterproof gran, aviation connector

■ Seal: FKM (fluorine rubber)
Technical parameters
Applicable media Dry gas, gas, liquid, slightly corrosive liquid, viscous liquid
Measurement range -0.1-70MPa
Comprehensive precision ± 0.25%FS
Repeat Precision ≤± 0.1%FS/year
Zero temperature drift ±0.02FS/℃
Input voltage 12-36V DC
Output 4-20mA, 0-5V, 0-10V, etc.
Working temperature -35-80℃
Overload pressure 150%FS
Bursting pressure 200%FS
Ambient temperature

-35-60℃
Response time ＜3-10ms  (10...90%FS)
Vibration resistance ±20g 20-5000Hz
Lifetime ＞1*10^8 pressure cycles
Liquid texture Ceramics (Al2O3 96%)
Shell Material 304 stainless steel
Protection level Electrical part IP65 (optional IP68)
Electrical connection Terminal, Hoffmann connector
Electrical Protection Overload/Reverse Phase Protection
Seal FKM (fluorine rubber)
Installation method thread, flange
Weight about 0.4kg
