Home > Products > Flow Measurement > Gas Mass Flow Meters & Controllers > FTWM-1600 Series Micro-Flow Gas Mass Flow Meter
New
FTWM-1600 series micro liquid flow meter
designed for pipe diameters of 1-8 mm
Designed for medium and low speed flow measurement in liquid pipelines
LimitsmallRange3ml/min, with excellent performance in low flow rate and slow flow conditions, it is the first choice for flow measurement in laboratories, testing and other places.
● 5SCCM~30SLM span,
● Multiple connection options for easy installation and use
● Short response time
● outstanding performance in air compressor electronic metering
● adaptable mechanical connections allow easy installation in different application environments
| Sensor | |||
| Path | small 1mm, large 8mm | ||
| Flow range | 5SCCM~30SLM | ||
| Turndown Ratio | 100:1 | ||
| Accuracy | ±(1.5+0.2FS)% | ||
| Repeatability | 0.25% | ||
| Zero output drift | ±30mV | ||
| Output drift | ±0.12%/℃ | ||
| Response Time | 10 (default, 20, 50, 100, 200, 500, 1000 can be set) | ||
| Operating power | 8 ~ 18Vdc,50mA | ||
| Output type | RS485, RS232, analog voltage 0.5~4.5Vdc | ||
