DOWESTONTVG-M2 2-Valve ManifoldAvailable in a variety of designs, they can be used with any instrument.
One available design has an isolation valve and a valve that controls a 1/2" FNPT vent valve.The use of two isolation valves in DP applications provides a monoblock design.
Threads underneath FKM O-ring seal and PTFE gasket prevent corrosion and wear; soft seat comes standard with Delrin seat
PTFE or Grafoil packing optional
All stems are 316SS
Vinyl dust cap (not packaged)
Rolled thread strength, durability and ease of use
All valves are helium leak tested for optimal performance
Valve body material: 316 stainless steel, galvanized carbon steel
Pressure level:Hard Seat - 10,000 psi at 200°F, Soft Seat - 6000 psi at 200°F.See the pressure/temperature chart on page 91 for more details.
Aperture: 0.187"; Mini: 0.156"
flow:Hard valve seat CV: 0.44, soft valve seat CV: 0.76
Connection method:Available with single flange or double flange connections for remote or direct installation
