Home > Products > Product Under Maintenance > FTR-Converter10 Compact Signal Converter
FTR-Converter10 Compact Signal Converter - Product Detail 1 - DOWESTON

FTR-Converter10
Compact Signal Converter

FTR-1600VTE02 signal amplifier detects the rotation speed of DOWESTON flow meter. Each passi...
  • Factory Direct
    Chengdu production base, every unit calibrated before shipping
  • Fast Delivery
    Standard models in stock, custom builds on schedule
  • Technical Support
    Selection guidance / installation and commissioning / after-sales support
Get a Quote and Selection Advice Download Technical Documents
Brand: DOWESTONWarranty: 12 monthsOEM / customization supported

Product Overview

OVERVIEW

FTR-1600VTE02 signal amplifier detects the rotation speed of DOWESTON flow meter. Each passing tooth is picked up without contact and generates a pulse at the output. Therefore, each pulse corresponds to a fixed volume and the frequency corresponds to the volumetric flow rate. Versions are available with push-pull output or explosion-proof sensor output (option: open collector output). The pickup is threaded into the meter via M14x1.5 threads. Therefore, the VTE 02 is suitable for all Doweston measuring cells.







Features

FEATURES




Specifications

SPECIFICATIONS
power supply voltage:
UB: +5 to 30 VDC, adjustable, depending on version
Quiescent current:
IR < 1 mA
Frequency range:
0.5 to 5000 Hz, depending on flow meter
ambient temperature:
-40°C to +80°C [-40°F to +176°F], depending on version
process medium temperature:
-40°C to +150°C [-40°F to +302°F]
output signal:
Pulse, 4-20mA
Pre-protection:
Group A, B, C, D Category I Section 1 T4





Downloads

DOWNLOADS
  • Brochures
  • User Manuals
  • Drawings and Software
