PD-210B sapphire pressure sensor
High precision, very highTouch temperature performance, high temperature pressureMeasurement
PD-210B sapphire pressure sensorCombined with aerospace-grade sapphire sensing elementComponents, combined with advanced circuit processing and temperature compensation technology, convert pressure changes into linear standard current or voltage signals, withFeatures include strong high temperature resistance, high sensitivity, high overload protection, and fast response speed., suitable forwith a certainMildly corrosive fluids and gaseous media, Multiple output options, withThreaded, FlangedAnd other connection methods to meet the needs of different working conditions.
■ Measuring medium: dry gas, gas, liquid, slightly corrosive liquid, viscous liquid
■ Measuring range: -0.1-150MPa
■ Overall Accuracy: ±0.1%FS
■ diaphragm Material: ceramics (Al2O3 96%)
■ Operating temperature: -40-180℃
■ Overload pressure: 150%FS
■ Burst pressure: 200%FS
■ Output: 4-20 mA, 0-5 V, 0-10 V, etc.
■ Process connection: threaded, flanged
■ Protective connections: Horsmann connectors, direct wiring, waterproof glands, aviation connectors
■ Seal: FKM (fluorine rubber)
| Compatible Media | Dry gases, gases, liquids, mildly corrosive liquids, viscous liquids |
| Measuring Range | -0.1-150MPa |
| Overall Accuracy | ±0.15%FS |
| Repeatability | ≤ ±0.1% FS/year |
| Zero-point Thermal Drift | ±0.02FS/°C |
| Input Voltage | 12-36V DC |
| Output | 4-20 mA, 0-5 V, 0-10 V, etc. |
| Operating Temperature | -40-180°C |
| Overload Pressure | 150%FS |
| Burst Pressure | 200%FS |
| Ambient Temperature | -40-80°C |
| Response Time | <3-10ms (10...90%FS) |
| Vibration resistance | ±20g 20-5000Hz |
| Service Life | >1x10^8 pressure cycles |
| Wetted Material | 31L stainless steel |
| Housing Material | stainless steel 304 |
| Protection Rating | Electrical: IP65 (IP68 optional) |
| Electrical Connection | Terminal blocks, Horsmann connectors, |
| Electrical Protection | Overload/Reverse Polarity Protection |
| Seal | FKM (fluorine rubber) |
| Mounting Type | Threaded, Flanged |
| Weight | Approx. 0.4 kg |
Application Areas:
■ PD-210B sapphire pressure sensorIt is widely used in applications that require direct measurement of high temperature, fast response speed, and high precision to measure the pressure of liquids, gases, and steam.
